NL-100T Series Lead Free Brass Ball Valve 600 WOG Full Port NPT Threaded Ends CSA/UL/FM

(0) No Reviews yet
SKU: NL-100T
Available in Box/Bag Qty Only: *
- 1/4" ~ 3/4": 10/BOX
- 1": 6/BOX
- 1-1/4" ~ 1-1/2": 4/BOX
- 2" ~ 2-1/2": 2/BOX
- 3" ~4": 1/BOX

This item is IN STOCK

Features

  • Valves conform to: MSS SP-110
  • Threaded ends to: ANSI B1.20.1
  • Valve markings conforms to MSS SP-25
  • CSA Approved ¼” to 4”
  • CUPC, NSF, UL/cUL listed (MH45831,1901), FM Approved ¼” to 2”
  • CUPC, NSF,CGA 2½ “ – 4”
  • Full Port for all sizes
  • Blow-out proof stem
  • *Maximum working pressure ½” – 2”: 600 WOG; 2-1/2” – 4”: 400 WOG,150 SWP 175 PSIG w/ ½ psi Gas,5 psi Gas & 125 psi Gas
  • Each valve is individually tested
  • Low operating torques
  • Hard Chromium plated solid brass ball
  • Fast ¼ turn for open/close operation
  • Temperature range: -40ºC ~ 185ºC (-40ºF ~ 366ºF)
  • 2 Adjustable packing gland
  • 2 piece body
  • Certified to: CGA 9.1a/ANSI Z21.15a, CR91-002, ASME B16.44 CAN/CGA-3.16-M88, ASME B16.33-2002, CGA 9.1-M97

Detailed Product Information (PDF)
